SelectedGGroup7 = 7
SelectedGGroup8 = 8
SelectedGGroup9 = 9
SelectedGGroup10 = 11
SelectedGGroup12 = 12
SelectedGGroup13 = 13
SelectedGGroup14 = 14
SelectedGGroup15 = 15
SelectedGGroup16 = 16
[Selected G-Groups ISO-Mode]
... (as with section for Siemens)
Procedure
1. Copy the "slmagcodeconfig.ini" file from the folder
/siemens/sinumerik/hmi/template/cfg.
2. Place the file in the following directory: /oem/sinumerik/hmi/cfg or /user/sinumerik/hmi/cfg.
As soon as the file is located in the user-specific directory, the entries for this file take
precedence over the Siemens file. If an entry is missing in a user-specific file, the
corresponding entry from the Siemens file is used instead.
3. Open the file and enter the number of the G code in question at the required position
"SelectedGGroup1 = 5".
I.e. the 5th G code group will be displayed at the 1st position.
8.4 Configuring the channel operational message
Overview
The channel operational messages are displayed in the third line of the header in the "Machine"
operating area. There are two types of channel operational messages:
1. Channel operational messages that require an operator action to continue a program, e.g.
feed enable missing, M01 active.
The channel operational messages are identified by exclamation marks.
2. Channel operational messages that do not require an operator action to continue a program.
A stop condition is active for a length of time (>1 s) and is interrupted by the program
processing, e.g. dwell time active, waiting for tool change.
The channel operational message is identified by a clock icon and disappears after a certain
time.
File
The settings for this are specified in the "slmahdconfig.ini" file.
Customizing the "Machine" operating area
8.4 Configuring the channel operational message
SINUMERIK Operate (IM9)
120 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
