19.7 Example: This is how you create an online help for NC/PLC variables
Overview
In order to create context-sensitive online help for NC/PLC variables or system variables as
shown in the following example, the descriptive texts are managed in language-dependent
html files.
Figure 19-1 Example: Online help for user variables
Structure of the online help
The following files are required for the online help:
File Meaning
sldgvarviewhelp.ini Configuration file to manage an html file or several html
files
<lng>/<name>1.html The contents of all html files of the online help are lan‐
guage-dependent and are saved in the relevant language
directory <lng>.
<lng>/<name>2.html
. . .
<lng>/<name>n.html
OEM-specific online help
19.7 Example: This is how you create an online help for NC/PLC variables
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 495
