Bit 3 = 1 Selects the probe calibration data, enable
Bit 6 = 1 Selects ZO correction in the basis reference (SETFRAME), enable
Bit 7 = 1 Selects ZO correction in channel-specific basic frames, enable
Bit 8 = 1 Selects ZO correction in the global basic frame, enable
Bit 9 = 1 Selects ZO correction in adjustable frames, enable
Bit 16 = 1 Selects workpiece measurement with spindle reversal
Bit 17 = 1 Selects align workpiece probe in the switching direction
Bit 28 = 1 Selects adjust workpiece length, enable
21.10.3.2 Measuring tools at the milling machines
Measuring feedrate for tool measurement in JOG and AUTOMATIC
SD55628 $SCS_MEA_TP_FEED_MEASURE Calibrate measuring feedrate for tool
probe and measure tool with station‐
ary spindle.
= 300 Default value
Note
Measuring feedrate for tool measuring
All measuring cycles use the value saved in SD54636 or SD54651 as the measuring feedrate
after the tool probe has been calibrated. A different measuring feedrate can be assigned for
each calibration field [n].
When calibrating the probe, either the measuring feedrate from
SD55628 SCS_MEA_TP_FEED_MEASURE is used, or the measuring feedrate can be
overwritten in the input screen when calibrating. To do this,
SD54762 $SNS_MEA_FUNCTION_MASK_TOOL bit 4 must be set to 1.
In the following setting data, index [k] stands for the number of the current data field (probe
number -1) of the probe.
SD54633 $SNS_MEA_TP_TYPE[k] Probe type, cube/disk
= 0 Compatibility (measuring cycles: cube, turning surface shows probe, milling surface shows
disk)
= 101 Disk in XY, working plane G17
= 201 Disk in ZX, working plane G18
= 301 Disk in YZ, working plane G19
= 2 Probe
= 3 Cube
The following setting data is used to define in which axes and directions it is possible to calibrate
a tool probe.
SD54632 $SNS_MEA_T_PROBE_ALLOW_AX_DIR[k] Axes and directions for "calibration"
= 133 Default value
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
628 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
