MD52207 $MCS_AXIS_USAGE_ATTRIB[n] Attributes of the axes
[n] channel axis number
Bit 6 Request rotational axis as offset target for measuring
= 0 Default value
= 1 Rotary axis is displayed as offset target in the "Measuring in JOG" window
Bit 9 SPOS behavior of main spindle influenced in connection with measuring cycles
= 0 The positioning behavior of the tool spindle is not influenced
= 1 The measuring cycles do not position the tool spindle (no SPOS)
Note
If the tool spindle is never SPOS-capable, Bit 9 = 1 must be set.
MD51751 $MNS_J_MEA_M_DIST_MANUELL Measurement path in mm, in front of and
behind the measurement point
= 10 Default value
MD51757 $MNS_J_MEA_COLL_MONIT_FEED Position feedrate in mm/min, in the working
plane for active collision monitoring
= 1000 Default value
MD51758 $MNS_J_MEA_COLL_MONIT_POS_FEED Position feedrate in mm/min, in the infeed
axis for active collision monitoring
= 1000 Default value
MD51770 $MNS_J_MEA_CAL_RING_DIAM[n] Pre-assignment of the calibration ring diam‐
eter in mm specifically for the calibration da‐
ta sets
= -1 Default value
MD51772 $MNS_J_MEA_CAL_HEIGHT_FEEDAX[n] Pre-assignment of the calibration height
in mm in the infeed axis, specifically for
the calibration data sets
= -99999 Default value
General cycle setting data
SD54780 $SNS_J_MEA_FUNCTION_MASK_PIECE Configuration of the input screens for
measuring in the "Machine" operating
area in the JOG operating mode
= 512 Default value
Bit 2 = 1 Activates measurements with an electronic probe
Technologies and cycles
21.10 Measuring cycles and measurement functions
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 627
