The following parameters are assigned to the cutting edges of the grinding tool:
Identifier/parameter Meaning
GrindingMonitoring Grinding-specific tool monitoring
GrindingUseBaseLength Taking into account the base dimension when calculating the
grinding wheel radius
12.2.2.5 Magazine location parameter identifiers
For the magazine location parameters, the following identifiers are used in the configuration
file:
Identifier Parameter or property System variable
*)
MagPlaceKind Location kind $TC_MPP1
MagPlaceType Location type $TC_MPP2
MagPlaceTypeIdent Location type as text $TC_MPP2
MagPlaceTNo Tool number of the tool in this location $TC_MPP6
MagPlaceWatchNeighbour Consider adjacent location $TC_MPP3
MagPlaceStateLocked Magazine location locked $TC_MPP4, Bit0
MagPlaceStateEmpty Magazine location free $TC_MPP4, Bit1
MagPlaceStateResInterMag Reserved for tool in buffer $TC_MPP4, Bit2
MagPlaceStateResLoadTool Reserved for tool to be loaded $TC_MPP4, Bit3
MagPlaceStateOccupiedLeft Magazine location occupied, left half location $TC_MPP4, Bit4
MagPlaceStateOccupiedRight Magazine location occupied, right half loca‐
tion
$TC_MPP4, Bit5
MagPlaceStateOccupiedUpper Magazine location occupied, upper half loca‐
tion
$TC_MPP4, Bit6
MagPlaceStateOccupiedDown Magazine location occupied, lower half loca‐
tion
$TC_MPP4, Bit7
MagPlaceStateReservedLeft Magazine location reserved, left half location $TC_MPP4, Bit8
MagPlaceStateReservedRight Magazine location reserved, right half location $TC_MPP4, Bit9
MagPlaceStateReservedUpper Magazine location reserved, upper half loca‐
tion
$TC_MPP4, Bit10
MagPlaceStateReservedDown Magazine location reserved, lower half loca‐
tion
$TC_MPP4, Bit11
MagPlaceMagazineNo Magazine number -
MagPlaceTypeIdx Type index $TC_MPP5
MagPlaceWearGroup Wear group number $TC_MPP5
MagPlaceAdaptNo Adapter number $TC_MPP7
MagPlaceNo Magazine location number -
MagNoMagPlaceNo Magazine number/Magazine location number -
MagPlaceUser_1, ... MagPla‐
ceUser_10
OEM magazine location parameters 1 to 10 $TC_MPPC1, ...
$TC_MPPC10
MagPlaceAppl_1, ... MagPla‐
ceAppl_10
Siemens magazine location parameters 1 to
10
$TC_MPPCS1, ...
$TC_MPPCS10
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
188 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
