Additional settings
MD52005 $MCS_DISP_PLANE_MILL Plane selection G17, G18, G19
= 0 Milling: Plane selection in the cycle support when programming under "programGUIDE G
code"
= 17 G17 plane (default value)
= 18 G18 plane
= 19 G19 plane
MD52006 $MCS_DISP_PLANE_TURN Plane selection G17, G18, G19
= 18 G18 plane (permanently set)
MD52212 $MCS_FUNCTION_MASK_TECH Cross-technology function screen
Bit 0 Enable swivel
= 0 Swivel plane, swivel tool not enabled
= 1 Swivel plane, swivel tool enabled
Bit 1 No optimized travel along software limit switches
= 0 No optimized travel along software limit switches
= 1 Optimized travel along software limit switches
MD52240 $MCS_NAME_TOOL_CHANGE_PROG Tool change program for G code steps
= Program name The associated program is called for tool change.
See also
Technology cycles for swiveling (Page 558)
21.2 Technology cycles for drilling
Drilling technology
You can set drilling technology using the following channel-specific configuration machine data
and channel-specific cycle setting data.
MD52216 $MCS_FUNCTION_MASK_DRILL Drilling function screen form
Bit 0 Tapping cycle CYCLE84, technology input fields
= 0 Hide input fields
= 1 Display input fields
Bit 1 Tapping cycle CYCLE840, technology input fields
= 0 Hide input fields
= 1 Display input fields
Technologies and cycles
21.2 Technology cycles for drilling
SINUMERIK Operate (IM9)
508 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
