"Easy" input in cycle support
You can influence the number of visible input parameters via MD52210
$MCS_FUNCTION_MASK_DISP with bit 9:
● All input parameters are displayed with the default setting bit 9 = 0 for "Complete".
● With the setting bit 9 = 1, you can select "Complete" or "Easy" input parameters in the cycle
support.
If you select the "Easy" input screen for input of the parameters, the values from the following
setting data are used for the invisible parameters (can be adapted machine-specifically):
SD55300 $SCS_EASY_SAFETY_CLEARANCE Easy input: Safety clearance
= 1 mm
SD55301 $SCS_EASY_DWELL_TIME Easy input: Dwell time
= 0.6 s
SD55305 $SCS_EASY_DRILL_DEEP_FD1 Easy input: Percentage of 1st deep-hole drill‐
ing feedrate
= 90 %
SD55306 $SCS_EASY_DRILL_DEEP_DF Easy input: Percentage of deep-hole drilling
infeed
= 90 %
SD55307 $SCS_EASY_DRILL_DEEP_V1 Easy input: Min. deep-hole drilling depth infeed
= 1.2 mm
SD55308 $SCS_EASY_DRILL_DEEP_V2 Easy input: Deep-hole drilling retraction dis‐
tance
= 1.4 mm
SD55309 $SCS_EASY_THREAD_RETURN_DIST Easy input: Thread turning return distance
= 2 mm
Note
The specified default values are valid for the metric system and are converted by the NC
automatically on the machine with the inch setting.
Technologies and cycles
21.1 Activating turning/milling/drilling/grinding technologies
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 507
