7.9 Managing data
Overview
The "Manage data" function is used to simplify the commissioning and permits the transfer,
backup, loading and comparing of machine, setting, compensation and drive data at the file
level. The files are saved in the .tea ASCII format.
The "Manage data" softkey is visible as of access level "Service" (= 2).
The following option fields are available in the "Transfer Machine Data" window:
● Transfer data within the controller
Only those controller objects are listed that are currently available in the controller.
● Save data to a file
Additional files with the extensions .acx and .log are created for the SINAMICS parameters:
– Files with the extension .acx contain the parameter descriptions for the selected drive
object.
– The log file may also contain the warnings and errors that occurred during the conversion
from .acx to .tea.
● Load data from a file
Note
An NCK and drive reset is only triggered automatically for drive objects after loading. A
reset must be triggered manually for all other controller objects.
● Compare data
Several files (.tea) and/or controller objects (axis, channel, servo, infeed, etc. ) can be
compared at the same time. An online comparison of constantly changing data is not
possible because the values are saved temporarily at the time of the comparison.
Up to eight elements can be taken into the list of the data to be compared.
Procedure
1. Select the "Start-up" operating area.
2. Press the "Mach. data" softkey.
The "Manage data" softkey is available in each machine data area, except
in "User views".
- OR -
Press the "System data" softkey and select the HMI data/Data backups/
IB data directory.
3. Press the "Manage data" softkey.
The "Transfer Machine Data" window opens.
4. Activate the required option filed and press "OK".
Machine and setting data
