Identifier Parameter or property System variable
*)
ToolMaxAcc Maximum acceleration $TC_TP_MAX_AC
C
ToolInMultiTool Multitool in which the tool is located $A_TOOLMTN
ToolInMultiToolPlace Multitool location containing the tool $A_TOOLMTLN
ToolMyMultiTool Owner multitool of the tool $A_MYMTN
ToolMyMultiToolPlace Owner multitool location of the tool $A_MYMTLN
ToolAlarmIsExtended PLC tool status - function "extended alarm" ac‐
tive
-
ToolAlarmLimit PLC tool status - alarm limit reached -
ToolExtAlarmLimit PLC tool status - limit "extended alarm" reached -
ToolUser_1, ... ToolUser_10 OEM tool parameters 1 to 10 $TC_TPC1, ...
$TC_TPC10
ToolAppl_1, ... ToolAppl_10 Siemens application tool parameters 1 to 10 $TC_TPCS1, ...
$TC_TPCS10
*)
Parameter corresponds to the system variable or the system variable is the basis for this parameter.
Note
Tool name "ToolIdent"
The maximum length of tool names is 31 ASCII characters.
The number of characters is reduced for Asian characters or Unicode characters.
The following special characters are not permitted: | # "
12.2.2.2 Cutting edge parameter identifiers
For the cutting edge parameters, the following identifiers are used in the configuration file:
Identifier Parameter or property System variable
*)
EdgeNo D number -
EdgeNoIdx Cutting edge number -
ToolType Tool type, cutting edge parameter 1 $TC_DP1
CuttEdgePos Cutting edge position, cutting edge param‐
eter 2
$TC_DP2
GeoLength1 Length 1, cutting edge parameter 3 $TC_DP3
GeoLengthGeoAx1 Length of geometry axis 1, cutting edge
parameter 3, e.g. length X
$TC_DP3
GeoLengthGeoAx1DiscDiameter Grinding wheel diameter in geometry axis
1, cutting edge parameter 3
$TC_DP3
GeoLengthGeoAx1DresserDiameter Dressing tool diameter in geometry axis 1,
cutting edge parameter 3
$TC_DP3
GeoLength Length, cutting edge parameter 3 $TC_DP3
GeoLength2 Length 2, cutting edge parameter 4 $TC_DP4
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 183
