18.13.2 Displaying PROFIBUS/PROFINET diagnostics
Diagnostics information from the DP master systems
From the user interface, you can display the fieldbus diagnostics known from HMIPRO. The
module state is displayed using diagnostic symbols.
The following diagnostics information is displayed depending on the particular version that you
have configured:
Information for all versions
Status Module has a fault
Module has failed
Module is OK
Module is suppressed (this is only possible with HMI PRO RT)
PROFIBUS address PROFIBUS address data
Additional information for the second version
PROFIBUS/PROFINET module
or channel diagnostics
Device diagnostics For Siemens DP/DP coupler and diagnostics repeater
Additional diagnostic information for the third version
Name Module designation from the HMI offline data
Name Module name from the HMI offline data
Order no. Order number of the module from the HMI offline data
IP address IP address of the module from HMI offline data (only for PROFINET)
Graphic display of the complete hardware configuration in a dedicated window
Procedure
1. Select the "Diagnostics" operating area.
2. Press the "Menu forward" key twice and the "PB/PN diag." softkey.
The "PROFIBUS/PROFINET Diagnostics" window opens.
3. Select the required DP master system.
The complete diagnostics information is displayed.
Service and diagnostics
18.13 PROFIBUS/PROFINET and AS-i bus diagnostics
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 477
