5. Select the corresponding rule for the relevant network profile:
– File and Printer Sharing (Echo Request - ICMPv4-In) - Profile "Domain"
– File and Printer Sharing (Echo Request - ICMPv4-In) - Profile "Public"
– File and Printer Sharing (Echo Request - ICMPv4-In) - Profile "Private"
In the factory setting state, the network profile "Public" is assigned to the company network.
Figure 4-6 Rules for incoming ICMP pings, separate for each network profile
6. Right-click on the selected rule, then click "Enable Rule".
4.17.9.2 By prompt, script or batch file
Basic procedure
With a command according to the following scheme, you can permit ICMP pings which arrive
at the company network interface (X1) of the Siemens PC system. Outgoing pings from the
Siemens PC system are already activated.
Note
Dependency for the file and printer release
If you activated the file and printer release in the company network, incoming ping requests
are already permitted because they are required for the file and printer release.
The name of the relevant firewall rule is "File and Printer Sharing (Echo Request - ICMPv4-
In)". To do this, call the prompt as the administrator and enter the command either completely
or successively.
Alternatively, you can save the command and the associated parameters in a script or batch
file (Page 70).
Syntax for activating a firewall rule via the prompt
netsh advfirewall firewall set rule name="<Name of the firewall rule>" new enable=yes
profile=<Name of the network profile>
Configuration of the system
4.17 Adapting the firewall settings
PCU Base Software (IM10)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 89
