HT 8
24
24.1 Configuring the traversing keys
The traversing keys of the HT 8 are not labeled as their type of action is not predefined. The
labeling of the traversing keys should adapt dynamically to the type of action of the keys. To
recognize the type of action of the traversing keys, they are shown within the display in the
vertical softkey area.
The menu of the traversing keys consists of two vertical rows each with eight keys so that up
to 16 texts can be configured. The top and bottom traversing key row remain empty and can
be assigned other functions.
The following data can be displayed:
● Machine axis name
● Alias name for machine axis
● Any language-dependent text
● Symbol
The following user-specific files are required. You can use the sample files as template:
File Meaning
"sljkconfig.ini" configuration file File in which the traversing keys are configured.
Text file "oem_sljk_xxx.ts" File for labeling traversing keys in a foreign language, xxx =
language code
"sljkconfig.ini" configuration file
Entries Meaning
[State_1] Labeling type - changed via the PLC.
ParamText_x_y Text of the traversing key that is made up of parameters.
Two-line labeling is possible, whereby max. five characters are possible per line.
x: Specifies the position of the key within the row (2 to 7).
y: Specifies the key row (1 or 2).
%m1 The machine axis name of the first axis is referenced and displayed as
text. The current active axis number is read out from data block DB10.
The name from the machine data is determined via this index.
%n Defines the position in the text for the line break.
%a1 The alias axis name of the first axis is referenced and displayed as text.
The current active axis number is read out from data block DB10. The
name from the "oem_sljk_eng.ts" text file is determined via this index.
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 681
