3.8 Changing the skin design
Displaying the machine data
You can change the skin design via the following item of machine data.
MD9112 $MM_HMI_SKIN Skin design
The number of the skin is indicated
= 0 Skin 0 (traditional)
= 1 Skin 1 (SINUMERIK Operate Generation 2)
After changing the machine data, the operating software must be restarted.
3.9 Setting the screensaver
Defining the time until the screen is darkened (screensaver)
The duration (in minutes), after which the screen is automatically darkened if no keyboard key
is pressed, can be specified using the display machine data
MD9006 $MM_DISPLAY_SWITCH_OFF_INTERVAL.
NOTICE
Influence of screen darkening on the service life
To extend its service life, the recommended duration for darkening a screen is 60 minutes.
If you significantly reduce the duration, i.e. the screen is switched dark too often, this tends
to shorten the screen service life.
Interface signal
The screen is darkened by setting an interface signal.
DB 19 byte Signals to the operator panel front (PLC → HMI)
DBB0 Bit 1 Bit 0
Darken screen Brighten screen
The following applies when actively darkening the screen using the interface signal:
● It is no longer possible to light up the screen again from the keyboard.
● The first keystroke on the operator panel already triggers an operator action.
Note
In order to prevent accidental operator actions via the interface signal when the screen is
darkened, we recommend disabling the keyboard at the same time.
General settings
3.9 Setting the screensaver
SINUMERIK Operate (IM9)
36 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
