Page #180 background imageLoading...
Page #180 background image
12.1.3 Additional settings
Additional settings
You can enable further functions on the user interface via the following machine data / setting
data:
MD52270 $MCS_TM_FUNCTION_MASK
Bit 0 Creating a tool at the magazine location is not permitted.
Bit 1 Load/unload lock if the machine is not in the reset state.
Bit 2 Load/unload lock for emergency stop.
Bit 3 Loading/unloading or relocating tool in/out of buffer.
Bit 4 Tool loaded directly into spindle.
Bit 5 Using the grinding configuration file.
Bit 6 Relocating a tool in/out of buffer is permitted despite lock (see bit 3).
Bit 7 Tool is created using the number.
Bit 8 Hide tool relocation.
Bit 9 Hide magazine positioning.
Bit 10 Reactivate tool with magazine positioning.
Bit 11 Reactivate tool in all monitoring types.
Bit 12 Hide reactivating tool.
SD54215 $SNS_TM_FUNCTION_MASK_SET
Bit 0 Diameter display for rotating tools.
Cutting edge parameters 6 (tool nose radius) and 15 (wear radius) are not displayed as a
radius value, but as a diameter value for the following tool types: Types 100 to 299, 580,
710, 711, 712, 713, 714 and 725.
Cutting edge parameter 7 (outside radius) is not displayed as a radius value, but as a diam‐
eter value for the following tool types: Types 140 and 714.
Bit 1 M4 is the standard direction of rotation for all turning tools. When creating turning tools, the
direction of rotation is pre-assigned with M4.
Bit 2 A name is not suggested when creating a tool.
Bit 3 Input lock, tool name and tool type for loaded tools. For loaded tools, the tool name and the
tool type can no longer be changed.
Bit 4 Input lock for loaded tools if the channel is not in the reset state.
Bit 5 Tool wear entries are added: Wear data is entered in addition to the already existing wear
value.
Bit 6 Only numerical entries are permitted in the "Tool identifier".
Bit 7 Hide tool monitoring parameters. The tool monitoring parameters are hidden in the user
interface.
Bit 8 Diameter display for face axis - geometry. The geometry value of the transverse axis is
displayed as a diameter value, if a transverse axis is defined in MD20100 $DIAME‐
TER_AX_DEF and SD42940 $TOOL_LENGTH_CONST is set to 18 and SD42950
$TOOL_LENGTH_TYPE is set to 2.
Tool management
12.1 Machine data for tool management
SINUMERIK Operate (IM9)
166 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
