SD54606 $SNS_MEA_WP_TRIG_PLUS_DIR_AX3[n] Trigger point, plus direction,
3rd measuring axis opposite to the tool
direction. In the default case = 0.
SD54607 $SNS_MEA_WP_POS_DEV_AX1[n] Position deviation,
1st measuring axis in the plane.
SD54608 $SNS_MEA_WP_POS_DEV_AX2[n] Position deviation,
2nd measuring axis in the plane.
SD54609 $SNS_MEA_WP_STATUS_RT Calibration status of the axis positions
SD54610 $SNS_MEA_WP_STATUS_GEN[n] Calibration status
SD54611 $SNS_MEA_WP_FEED[n] Measuring feedrate when calibrating
21.10.4.3 Measuring tools at the milling machines
Settings
SD54762 $SNS_MEA_FUNCTION_MASK_TOOL Setting for the input screen, measuring
cycles in the automatic mode, tool meas‐
urement
Bit 3 Setting for the input screen, measuring cycles in the automatic mode, tool measurement,
enable tool probe calibration data field to be selected
Bit 4 Select calibration input measuring feed (VMS)
1)
Bit 5 Select input feedrate and spindle speeds when probing
Bit 7 Select measurement in MCS and WCS
Bit 8 Select measurement, absolute and incremental
Bit 9 Select tool offset, geometry and wear
Bit 10 Select individual cutting edge measurement
Bit 11 Selects spindle reversal when calibrating in the plane
Bit 12 Select number of measurements (_NMSP)
Bit 13 Select experience values (_EVNUM)
1)
Input, measurement feedrate is valid for AUTOMATIC and JOG
