Settings Purpose
Default Gateway Set the IP address of the standard gateway.
A standard gateway creates a standard route in the IP routing table for all destinations that are
not in the subnet.
Name Server Set the IP address of the name server.
A name server answers questions asked about a domain name zone using a DNS database.
4.16.3 Configuration of the host
You can make the network settings in the "Host Settings" tab and permanently save this
configuration, in contrast to the settings in the "Network Settings" dialog box of the Service
Center.
Settings that you make in this dialog box are stored in the servicesystem.ini configuration
file.
Overview
You can make the following settings in the "Host Settings" dialog box:
Figure 4-4 Host settings
Configuration of the system
4.16 Configuration of the Service Center
PCU Base Software (IM10)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 65
