Entries Meaning
MAGAZINE_XXX Number of the magazine whose locations will be assigned to the coordinate
system.
Places Number of magazine locations that will be assigned to the coordinate system.
Example
The following assignment between magazines or magazine locations and coordinate systems
is to apply:
Magazine 1,3, and 4 Coordinate system 34
Magazine 2 Coordinate system 33
Magazine 9998 location 2 Coordinate system 33
<COORDSYSMAGAZINEASSIGNMENT>
<COORDSYSNO_34>
<Magazines value="1 3 4" type="QString" />
</COORDSYSNO_34>
<COORDSYSNO_33>
<Magazines value="2" type="QString" />
<MAGAZINE_9998>
<Places value="2" type="QString" />
</MAGAZINE_9998>
</COORDSYSNO_33>
</COORDSYSMAGAZINEASSIGNMENT>
12.2.19 Disabling the softkey depending on filters
Tag <FILTERCONFIGURATION> in combination with Tag <SOFTKEYLOCK>
Some softkeys can be hidden depending on filter settings. For example, the "New Tool" softkey
is hidden if the filter "Only disabled tools" is set. This is not a good idea because the new tool
is not created as a disabled tool and is thus directly filtered out of the display. This means that
the new tool would not be displayed after being created.
Softkey identifiers of the softkey, which can be hidden:
Entries Meaning
NewTool New tool
Edges Cutting edges
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 215
