Page #196 background image
Identifier Parameter or property System variable
*)
ToolInMagInPlace Magazine number/Magazine location $A_TOOLMN /
$A_TOOL_MLN
ToolMonTCW Type of tool monitoring, tool life, workpiece
count and wear. If wear monitoring has not been
enabled via the machine data, this parameter is
handled like ToolMonTC.
$TC_TP9
ToolMonTC Type of tool monitoring, tool life and workpiece
count
$TC_TP9
ToolPlaceSpec Location type $TC_TP7
ToolPlaceSpecIdent Location type, if it is to be displayed as text. The
precondition is that the text for the location type
was configured.
$TC_TP7
ToolSearch Tool search type for replacement tools $TC_TP10
ToolMyMag Owner magazine of the tool $A_MYMN
ToolMyPlace Owner magazine location of the tool $A_MYMLN
ToolSizeLeft Tool size left in half locations $TC_TP3
ToolSizeRight Tool size right in half locations $TC_TP4
ToolSizeUpper Tool size upper in half locations $TC_TP5
ToolSizeDown Tool size lower in half locations $TC_TP6
ToolOverSize Tool size as fixed setting - two half locations left,
two half locations right, one half location top,
one half location bottom
$TC_TP3 -
$TC_TP6
ToolState Tool status in the hexadecimal notation $TC_TP8
ToolStateActiv Tool status - tool active $TC_TP8, Bit0
ToolStateEnabled Tool status - tool released $TC_TP8, Bit1
ToolStateLocked Tool status - tool locked $TC_TP8, Bit2
ToolStateLockedRO Tool status - tool locked, only read access $TC_TP8, Bit2
ToolStateMeasured Tool status - tool measured $TC_TP8, Bit3
ToolStatePrewarn Tool status - tool has reached prewarning limit $TC_TP8, Bit4
ToolStatePrewarnRO Tool status - tool has reached prewarning limit,
only read access
$TC_TP8, Bit4
ToolStateInChange Tool status - tool is being changed $TC_TP8, Bit5
ToolStateFixed Tool status - tool fixed place coded $TC_TP8, Bit6
ToolStateUsed Tool status - tool was in use $TC_TP8, Bit7
ToolStateAutoReturn Tool status - automatic return $TC_TP8
ToolStateIgnoreLocked Tool status - do not observe locked $TC_TP8, Bit9
ToolStateMarkedToUnload Tool status - tool is marked to unload $TC_TP8, Bit10
ToolStateMarkedToLoad Tool status - tool is marked to load $TC_TP8, Bit11
ToolStatePermanent Tool status - tool is permanent $TC_TP8, Bit12
ToolState1To1Exchange Tool status - one to one replacement $TC_TP8, Bit14
ToolStateHandTool Tool status - manual tool $TC_TP8, Bit15
ToolProtAreaFile File name of the tool description which is re‐
quired to define the protection zone
$TC_TP_PROTA
ToolMaxVelo Maximum speed $TC_TP_MAX_VE‐
LO
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
182 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
