Identifier Parameter or property System variable
*)
GeoLengthGeoAx3 Length of geometry axis 3, cutting edge
parameter 4, e.g. length Z
$TC_DP4
GeoLengthGeoAx3DiscDiameter Grinding wheel diameter in geometry axis
3, cutting edge parameter 4
$TC_DP4
GeoLengthGeoAx3DresserDiameter Dressing tool diameter in geometry axis 3,
cutting edge parameter 4
$TC_DP4
GeoLength3 Length 3, cutting edge parameter 5 $TC_DP5
GeoLengthGeoAx2 Length of geometry axis 2, cutting edge
parameter 5, e.g. length Y
$TC_DP5
GeoLengthGeoAx2DiscDiameter Grinding wheel diameter in geometry axis
2, cutting edge parameter 5
$TC_DP5
GeoLengthGeoAx2DresserDiameter Dressing tool diameter in geometry axis 2,
cutting edge parameter 5
$TC_DP5
GeoRadius Radius, cutting edge parameter 6 $TC_DP6
GeoOutsideRadius714 External radius for the star probe, tool type
714, cutting edge parameter 6
$TC_DP6
GeoCuttEdgeRadius Tool nose radius, cutting edge parameter
6
$TC_DP6
GeoCornerRadius Corner radius, cutting edge parameter 7 $TC_DP7
GeoOutsideRadius Outside radius, cutting edge parameter 7 $TC_DP7
GeoBoomLength Cantilever length, cutting edge parameter
7
$TC_DP7
GeoSlotWidth Slot width, for example, for slotting saw,
cutting edge parameter 7
$TC_DP7
GeoRadius714 Ball radius for the star probe, tool type 714,
cutting edge parameter 7
$TC_DP7
GeoLength4 Length 4, cutting edge parameter 8 $TC_DP8
PlateLength Cutting tip length, cutting edge parameter
8
$TC_DP8
GeoProjection Protrusion, for example, for slotting saw,
cutting edge parameter 8
$TC_DP8
GeoLength5 Length 5, cutting edge parameter 9 $TC_DP9
GeoWidth Width, cutting edge parameter 9 $TC_DP9
PlateWidth Cutting tip width, cutting edge parameter 9 $TC_DP9
GeoPitch Thread pitch, cutting edge parameter 9 $TC_DP9
BoreRadius Hole radius, cutting edge parameter 9 $TC_DP9
GeoAngle1 Angle 1, cutting edge parameter 10 $TC_DP10
HolderAngle Holder angle, cutting edge parameter 10 $TC_DP10
CorrectionAngle Correction angle to align the probe, cutting
edge parameter 10
$TC_DP10
GeoAngle2 Angle 2, cutting edge parameter 11 $TC_DP11
AngleConicalMillTool Angle conical mill tools, cutting edge pa‐
rameter 11
$TC_DP11
CuttDirection Reference direction holder angle, cutting
edge parameter 11
$TC_DP11
WearLength1 Wear length 1, cutting edge parameter 12 $TC_DP12
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
184 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
