Identifier Parameter or property System variable
*)
WearLengthGeoAx1 Wear length of geometry axis 1, cutting
edge parameter 12,
e.g. Δ length X
$TC_DP12
WearLength Wear length, cutting edge parameter 12 $TC_DP12
WearLength2 Wear length 2, cutting edge parameter 13 $TC_DP13
WearLengthGeoAx3 Wear length of geometry axis 3, cutting
edge parameter 13,
e.g. Δ length Z
$TC_DP13
WearLength3 Wear length 3, cutting edge parameter 14 $TC_DP14
WearLengthGeoAx2 Wear length of geometry axis 2, cutting
edge parameter 14,
e.g. Δ length Y
$TC_DP14
WearRadius Wear radius, cutting edge parameter 15 $TC_DP15
WearOutsideRadius714 Wear external radius for the star probe,
tool type 714, cutting edge parameter 15
$TC_DP15
WearCuttEdgeRadius Wear tool nose radius, cutting edge pa‐
rameter 15
$TC_DP15
WearCornerRadius Wear corner radius, cutting edge parame‐
ter 16
$TC_DP16
WearSlotWidth Wear slot width, for example, for slotting
saw, cutting edge parameter 16
$TC_DP16
WearLength4 Wear length 4, cutting edge parameter 17 $TC_DP17
WearProjection Wear protrusion, for example, for slotting
saw, cutting edge parameter 17
$TC_DP17
WearLength5 Wear length 5, cutting edge parameter 18 $TC_DP18
WearAngle1 Wear angle 1, cutting edge parameter 19 $TC_DP19
WearAngle2 Wear angle 2, cutting edge parameter 20 $TC_DP20
AdaptLength1 Adapter length 1, cutting edge parameter
21
$TC_DP21
AdaptLengthGeoAx1 Adapter length of geometry axis 1, cutting
edge parameter 21, e.g. adapter length X
$TC_DP21
AdaptLength Adapter length, cutting edge parameter 21 $TC_DP21
AdaptLength2 Adapter length 2, cutting edge parameter
22
$TC_DP22
AdaptLengthGeoAx3 Adapter length of geometry axis 3, cutting
edge parameter 22, e.g. adapter length Z
$TC_DP22
AdaptLength3 Adapter length 3, cutting edge parameter
23
$TC_DP23
AdaptLengthGeoAx2 Adapter length of geometry axis 2, cutting
edge parameter 23, e.g. adapter length Y
$TC_DP23
ReliefAngle Relief angle, cutting edge parameter 24 $TC_DP24
PlateAngle Cutting tip angle, combination of cutting
parameter 24 and cutting edge parameter
10
$TC_DP24 and
$TC_DP10
NoseAngle Nose angle, cutting edge parameter 24 $TC_DP24
CuttRate Cutting rate, cutting edge parameter 25 $TC_DP25
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 185
