HSK9 HSK10 HSK11 HSK12 HSK13 HSK14 HSK15 HSK16
-- Straight-line
circle
(only for
ShopMill)
-- -- Measure
workpiece
Measure tool OEM --
Milling
The following tables list the possible start softkeys for milling technology. Assignments of
individual start softkeys can differ depending on the particular system. The specified OEM
softkeys are permitted for "Run MyScreens".
programGUIDE (G-Code) start softkeys:
Drilling Milling Contour milling Turning Miscellaneous
HSK2 HSK3 HSK4 HSK5 HSK6
VSK1 Centering Face milling Contour -- Stock re‐
moval
Contour Settings --
VSK2 Drilling ream‐
ing
Pocket Path -- Groove Stock re‐
moval
Swivel plane Parallel
axes
VSK3 Deep-hole drill‐
ing
Multi-edge
spigot
Predrilling -- Undercut Stock re‐
moval re‐
sidual ma‐
terial
Swivel tool --
VSK4 Boring Groove Pocket -- Thread Grooving High speed set‐
tings
--
VSK5 Thread Thread mill‐
ing
Pocket res.
mat.
-- Parting Grooving
residual
material
-- --
VSK6 OEM Engraving Spigot -- -- Plunge-
turning
Subprogram --
VSK7 Positions OEM Spigot res.
mat.
OEM OEM Plunge
turning re‐
sidual ma‐
terial
-- OEM
VSK8 Repeat posi‐
tion.
-- >> << Contour
turning
<< >> <<
ShopMill start softkeys:
Drilling Milling Contour milling Miscellaneous Straight line circle
HSK2 HSK3 HSK4 HSK6 HSK10
VSK1 Centering Face milling New contour -- Settings -- Tool
VSK2 Drilling ream‐
ing
Pocket Path -- Swivel plane Parallel axes Straight line
VSK3 Deep-hole
drilling
Multi-edge
spigot
Predrilling -- Swivel tool Repeat progr. Circle center point
VSK4 Boring Groove Pocket -- High speed set‐
tings
-- Circle radius
VSK5 Thread Thread mill‐
ing
Pocket res. mat. -- Transforma‐
tions
-- Helix
Reference lists
A.1 Lists of start softkeys
SINUMERIK Integrate Run MyScreens (BE2)
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 291
