You can replace the Siemens logo with your own logo.
OEM-specific logo in traditional display
Procedure:
1. Name your own logo "logo.png".
Note
The file name must not contain any lower case letters.
2. Save your own logo depending on the bitmap size in one of the directories: /oem/sinumerik/
hmi/ico or /user/sinumerik/hmi/ico
Directory Bitmap size
/Ico640 122 x 19
/Ico800 160 x 24
/Ico1024 199 x 30
OEM-specific logo of Generation 2 display
Procedure:
1. Depending on the screen resolution, name your own logo
"company_label_XXXXxYYYY.png".
The placeholder XXXXxYYYY corresponds to the screen resolution, for example
"company_label_1024x768.png".
2. Save your own logo depending on the bitmap size in one of the directories: /oem/sinumerik/
hmi/skins/skin1/ico/ico640 or /user/sinumerik/hmi/skins/skin1/ico/ico640
Note
Display error
Remove your own logo "logo.png" from the directories /oem or /user when the Generation
2 display is used.
Your own logo must not exceed the header height in relation to the screen resolution used.
The following is allowed:
Screen resolution Maximum bitmap height
640 x 480 32
760 x 505 32
800 x 480 32
800 x 600 40
1080 x 810 53
1024 x 768 51
1024 x 1014 51
Customizing the "Machine" operating area
8.2 Inserting a user-specific logo
SINUMERIK Operate (IM9)
118 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
