Backing up and restoring data
4.4 Network settings in the Service Center
PCU-Basesoftware (IM8)
Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
91
You can make the following IP settings in the "Network Settings" dialog box:
Figure 4-2 Service Center - IP settings
Table 4- 2 IP settings in the "Network Settings" dialog box
Adapter configuration Adapter Select the Ethernet interface that you want to configure.
All settings in Section "Adapter configuration" refer to the selected Ethernet interface.
DHCP Enabled Select whether the addresses are to be fetched dynamically from the DHCP server.
If the checkbox is deactivated, you must make the settings manually.
Address Set the IP address of the NCU.
You can specify an IP address from the following range:
Specify a subnet mask, e.g. 255.255.255.0
Default Gateway Set the IP address of the standard gateway.
A standard gateway creates a standard route in the IP routing table for all destinations that
Name Server Set the IP address of the name server.
A name server answers questions asked about a domain name zone using a DNS database.
Host configuration Suffix Search List Parameterize a search list for DNS suffix, e.g. "network.com".
The factory setting of the Ethernet interface "Local Area Connection" is ".local".
