Backing up and restoring data
4.8 Restore a disk image of a partition
PCU-Basesoftware (IM8)
98 Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
3. Make the required settings here:
Base
parameters
Ghost version Select the Symantec Ghost version that is to be used when
creating the disk image:
• Version for Windows 7: "Ghost version 11.5.x"
• Version for Windows XP: "Ghost version 8.2.x"
Source partition Select a data medium of which you want to create a data
Destination file Enter a destination directory and file name.
Disk images can be stored either locally or in the network.
Base
parameters >
Destination file
Connect share Open the "Connect a Share" dialog box (Page 102).
You can set up a shared resource (e.g. a directory in the
network), to which you can store the disk image.
Select
destination
Call the "Select destination file" dialog.
You can navigate through a local directory on the PCU 50.5
Optional
parameters
Split image size Split the disk image and select a split image size.
You can split the disk image into several files of a defined size.
Split the disk image size in the following cases:
• If the file system (e.g. FAT32) can only manage files of a
certain size.
• If the disk image is to be archived onto multiple data
media, for example, when using CDs.
Compatible file
naming system
Select the compatibility of the name scheme.
This option is required so that a disk image with older versions
of the "PCU base software Windows XP" can be read in by
Windows XP.
It is not possible to use a different operating system on a PCU
50.x than the preinstalled system (e.g. Windows XP on a
Compress
Activate Compression or select a compression level.
Higher compression results in a smaller file size, but increases
the time needed to compress or decompress the data.
4. Confirm your settings with "Backup" to start generation of the disk image.
