Backing up and restoring data
4.9 Network settings in the Service Center
PCU-Basesoftware (IM8)
Commissioning Manual, 02/2014, 6FC5397-1DP40-4BA0
103
The setting options in the "Connect a share" dialog box have the following meaning:
Figure 4-8 "Connect a Share" dialog box
Table 4- 4 Settings in the "Connect a Share" dialog box in the Service Center
Connection
To select drive letters under which the network directories are to be accessible on the PCU 50.5.
Remote path Specify the device in the network and share name of the resource.
Syntax: \\Name of the server\share name of the network directory
Example: \\Backup_Server\PCU_Backup
Credentials User name Enter the user account under which the resource in the network can be accessed.
If you have shared the resource on the server for certain users only, you must enter one of these user
Enter the password of the user account.
You will find information about releasing directories in the network and network drives in the
following sections:
● Release directory of the PC/PC in the network (Page 114)
● Creating a shortcut to the network drive (Page 119)
