Entries Meaning
FixKindOfDistInMultiTools Multitools are created with a fixed type of clearance input of
the multitool locations. There is no prompt when you create
the multitool.
Possible input value: 3 - clearance of the multitool locations
as an angle.
DlDisplayMode
● DisplayDistributed - default setting, the setup offsets EC
are displayed in the tool list and the additive offsets SC
are displayed in the tool wear list.
● EcInWearList - the setup offsets EC are displayed in the
tool wear list and the additive offsets SC are not
displayed.
CombinedToolMonitoring Specifies the combined monitoring types offered in the tog‐
gle field:
● Time/Count - tool life and workpiece count
● Time/Wear - tool life and wear monitoring
● Count/Wear - workpiece count and wear monitoring
● Time/WearDlSc - tool life and wear monitoring for
additive and setup offsets
● Count/WearDlSc - workpiece count and wear monitoring
for additive and setup offsets
● Time/Count/Wear - tool life, workpiece count and wear
monitoring
● Time/Count/WearDlSc - tool life, workpiece count and
wear monitoring for additive and setup offsets
FiltersCombinedWithOr Defines the filter criteria, which are linked in the filter window
using a logical OR. The default setting for all the filter criteria
is a logical AND. The possible entries are:
● "StandBy" - for tools that are ready for use
● "Active" - for tools with active identifier
● "Locked" - for locked tools
● "Prewarn" - for the prewarning limit
● "RemainingPieces" - for the remaining unit quantity
● "RemainingTime" - for the remaining tool time
● "MarkedToUnload" - for the unload identifier
● "MarkedToLoad" - for the load identifier
AddToGrindingSpindles Defines the spindle numbers that are to be offered in the
"GrindingSpindleNo" ($TC_TPG1) parameter when select‐
ing the grinding spindles. The numbers of the grinding spin‐
dles must be separated by a space, e.g. -1 8 9.
Default display: real NC spindles and 0
HideGrindingSpindles Defines the spindle numbers of the real NC spindles that
are not to be offered in the "GrindingSpindleNo"
($TC_TPG1) parameter when selecting the grinding spin‐
dles. The numbers of the grinding spindles must be sepa‐
rated by a space, e.g. 1 3.
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 175
