Coding of tool types for drills
Group type 2xy (drills):
200 Twist drill
205 Solid drill
210 Boring bar
220 Center drill
230 Countersink
231 Counterbore
240 Tap regular thread
241 Tap fine thread
242 Tap Whitworth thread
250 Reamer
Coding of tool types for grinding tools
Group type 4xy (grinding tools):
400 Grinding wheel circumference
410 Face grinding wheel
490 Dresser
494 Dressing roller for cylindrical grinding
495 Dressing roller for surface grinding
496 Dressing wheel for cylindrical grinding
497 Dressing wheel for surface grinding
Grinding tool types 401, 402, 403 as well as 411, 412, 413 are not listed as tool types that can
be selected. The grinding-specific tool monitoring - taking into account the basic dimension
when calculating the grinding wheel radius - is set using dedicated parameters. These
parameters act on the tool types in the usual form.
Coding of tool types for turning tools
Group type 5xy (turning tools):
500 Roughing tool
510 Finishing tool
520 Plunge cutter
530 Parting tool
540 Threading tool
550 Steel profile
560 Rotary drill (ECOCUT)
580 Orientated probe
585 Calibration tool
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
196 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
