Tool type $TC_DP1 Default value $TC_DP25 Direction of spindle rotation
Type 730/731/732 Bit 8 = 0
Bit 9 = 0
Spindle stop
All other tool types
- Bit 8 = 1
Bit 9 = 0
Spindle right
Tool type $TC_DP1 Default value $TC_DP25 for switching direction
Type 712 mono probe Bit 17 = 1
Bit 20 = 1
Type 713 L probe Bit 17 = 1
Bit 21 = 1
Type 714 star probe Bit 16 = 1
Bit 17 = 1
Bit 18 = 1
Bit 19 = 1
Tool type $TC_DP1 Default value $TC_DP24 for tip angle
Type 200 twist drill 118
Type 220 centering tool 90
The plate angle rather than the clearance angle is displayed on the screen:
plate angle = 180 - holder angle - clearance angle
Tool type
$TC_DP1
Default values
Cutting edge position
$TC_DP2
Holder angle
$TC_DP10
Clearance angle
$TC_DP24
Type 500 roughing tool 1 to 4 95 5
5 to 8 50 50
Type 510 finishing tool 1 to 4 93 32
5 to 8 62.5 62.5
Type 560 rotary drill - 90 2
Tool type $TC_DP1 Unit of measure‐
ment
Default value $TC_DP8 for plate length
Type 500 roughing tool
Type 510 finishing tool
metric 11
inch 0.4
For all grinding tools, the parameter for calculating the radius:
$TC_TPG9 = 3 (corresponds to length 1) applies
Tool management
12.2 Configuring the user interface
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 207
