Deviations during the comparison are identified by being color-highlighted:
● Red: missing or non-accessible components compared with the reference topology.
● Pink: components that deviate in their attribute values compared with the reference
topology.
● Blue: new components not contained in the reference topology.
Saving
3. Press the "Save" softkey to save the current topology.
The "Save as" window opens.
4. Position the cursor on the desired option box, specify a file name and
possibly a comment, and confirm with "OK".
Note
Manufacturer topology and reference topology can be created with access level 3 (user) or
higher and are always saved on the active DHCP server.
Default storage locations:
● Current topology (.xml or .csv):
The following storage locations are offered depending on the configuration:
– Network topology (storage location: HMI-data / data backups)
– Local drive
– Network drives
– USB
In CSV format, ";" is preset as a separator; it can be changed in sldgconfig.xml
● Reference topology:
/user(_base)/common/tcu/$soll
● Manufacturer topology:
/oem(_base)/common/tcu/$soll
Configuring the network
17.6 Station-related network diagnostics
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 403
