Display data Meaning
Servo gain factor (calculated) The servo gain factor in the display is calculated by the NC according
to the following equation:
.YIDFWRU
6SHHGVHWSRLQW
)ROORZLQJHUURU
8QLWIRUGHIDXOWVHWWLQJ
>PPLQ@
>PP@
Velocity setpoint = setpoint currently being output to the axis/spindle
References:
Basic Functions Function Manual; Velocities, Setpoint / Actual Value
Systems, Closed-Loop Control (G2)
Active measuring system 0: No measuring system active.
1: Measuring system 1 active.
2: Measuring system 2 active.
State of measuring system 1
State of measuring system 2
The state of measuring system 1 or 2 is output here:
Active - Parked - Passive
Actual position value measur‐
ing system 1
The actual position of the axis measured via measuring system 1 or 2.
The position is displayed in the machine coordinate system (no work
offsets or tool offsets taken into account).
Unit: mm, inch or degrees
Actual position value measur‐
ing system 2
Position setpoint Specified position transferred from the interpolator to the position control
Unit: mm, inch or degrees
Absolute compensation value
measuring system 1
Display of the absolute compensation value for measuring system 1 or
2.
The compensation value consists of the sum of backlash and leadscrew
error compensation for the actual axis position.
Unit: mm, inch or degrees
Absolute compensation value
measuring system 2
Compensation, sag + tem‐
perature
Display of the compensation value calculated for the current axis posi‐
tion based on the total of the sag and temperature compensations.
Unit: mm, inch or degrees
Actual speed value, active
encoder
The pulses supplied by the encoder are evaluated by the NC and dis‐
played.
Unit: %
100% means maximum speed.
Speed setpoint, drive Speed setpoint transferred to the drive (= speed setpoint from position
controller and feedforward control).
Unit: %
100% means maximum speed setpoint.
Programmed spindle speed
setpoint
Speed setpoint programmed by the user.
Unit: rpm
e. g.: Input: S1000; display: 1000 rpm
Display applies to spindles only.
Service and diagnostics
18.2 Displaying the Service overview
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 415
