Page #438 background image
Ramp-up function completed
The status display of the drive as to whether the ramp-up has been completed corresponds
to the interface signal:
DB31, ... DBX94.2 "Ramp-up completed".
Status Meaning Display
1 The actual speed value has reached the speed tolerance band specified via
p2164 after a new speed setpoint specification and has not left the band for
the duration of p2166.
Yes
0 The ramp-up procedure is still active after the speed setpoint has been
changed.
No
Torque lower than threshold setting
The status display of the drive as to whether the threshold torque has been undershot
corresponds to the interface signal:
DB31, ... DBX94.3 "|M
d
| < M
dx
".
Status Meaning Display
1 The current torque utilization lies below the torque utilization threshold set in
p2194. The drive signals the PLC that the torque setpoint |M
d
| does not ex‐
ceed the threshold torque M
dx
.
Yes
0 The torque setpoint |M
d
| is larger than the threshold torque M
dx
. This signal
can be used to determine whether the motor is overloaded.
No
Speed lower than minimum setting
The status display of the drive as to whether the minimum speed has been undershot
corresponds to the interface signal:
DB31, ... DBX94.4 "|n
act
| < n
min
".
Status Meaning Display
1 The actual speed value |n
act
| is less than the threshold minimum speed n
min
set in p2161.
Yes
0 The actual speed value is greater than the threshold minimum speed. No
Speed lower than threshold setting
The status display of the drive as to whether the threshold speed has been undershot
corresponds to the interface signal:
DB31, ... DBX94.5 "|n
act
| < n
x
".
Status Meaning Display
1 The actual speed value |n
act
| is less than the threshold speed n
x
set in p2155. Yes
0 The actual speed value is greater than the set threshold speed. No
Service and diagnostics
18.2 Displaying the Service overview
SINUMERIK Operate (IM9)
424 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
