Attributes Meaning
● Block start, type 1 or block end (all program levels, without intermediate
blocks)
● Block start, type 2 or block end (all program levels, with intermediate blocks)
● Block start, type 3 or block end (all main programs, without intermediate
blocks)
● Block start or block end, block search (all program levels, without
intermediate blocks)
● Geo axis start / direction change (2nd event)
● Geo axis stop (2nd event)
● Block start, type 2 (2nd event: all program levels, without intermediate
blocks)
● Block end, type 2 (2nd event: all program levels, with intermediate blocks)
● Block start, block advance, type 1 (2nd event)
● OEM test event 1 (non-cyclic, block advance)
● OEM test event 2 (non-cyclic, main run)
● Activate/deactivate synchronized action
● Synchronized action initiated (condition fulfilled)
● Signaled alarm
● Cancel softkey pressed
● Program level change
● Block end (Interpreter)
● Trace end (last event!)
● Start trace
● WRTPR part program command
● WRTPR part program command (block search)
● Tool change
● Cutting edge change
● Tool change (block search)
● Cutting edge (block search)
● Start trigger initiated
● Stop trigger initiated
● Block end (block advance)
● Block end (2nd event: Block search)
● WRTPR part program command (block advance)
● Tool change (block advance)
● Cutting edge (block advance)
Event channel This means that the channel can be defined in SINUMERIK in which a specific
event occurs. For events which are not channel-specific, the field remains emp‐
ty.
Service and diagnostics
18.12 Trace
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 465
