MD20144 $MC_TRAFO_MODE_MASK
Bit 0 = 1 TRAANG runs in the background (persistent) and is not shown on the user interface.
MD20070 $MC_AXCONF_MACHAX_USED[4]
= 5 Channel axis YC = 5th machine axis.
MD20080 $MC_AXCONF_CHANAX_NAME_TAB[ ] Name of channel axis in the channel.
[0] = XC 1st channel axis XC
[1] = ZC 2nd channel axis ZC
[2] = C 3rd channel axis C
[3] = WZ 4th channel axis WZ
[4] = YC 5th channel axis YC
Data set for inclined axis:
MD24430 $MC_TRAFO_TYPE_5
= 1024 Transformation 5: TRAANG
MD24432 $MC_TRAFO_AXES_IN_5[ ] Axis assignment for transformation 5.
[0] = 5 1st transformation axis = channel axis, YC
[1] = 1 2nd transformation axis = channel axis, XC
[2] = 2 3rd transformation axis = channel axis, ZC
MD24434 $MC_TRAFO_GEOAX_ASSIGN_TAB_5[ ] Assignment of geometry axes to channel
axes for transformation 5.
[0] = 1 1st axis = channel axis XC
[1] = 5 2nd axis = channel axis YC
[2] = 2 3rd axis = channel axis ZC
MD24436 $MC_TRAFO_INCLUDES_TOOL_5
= 0 Tool handling with active transformation 5.
MD24700 $MC_TRAANG_ANGLE_1
= 55 Angle between 1st and 2nd transformation axis. Data set for linking (TRACON) of end
face machining on main spindle (TRANSMIT) and inclined axis (TRAANG).
Data set for linking (TRACON) of end face machining on main spindle (TRANSMIT) and
inclined axis (TRAANG):
MD24440 $MC_TRAFO_TYPE_6
= 8192 Type of transformation that is available as sixth in the channel.
Technologies and cycles
21.5 Turning
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 553
