References
● "siemensd.txt" file in the supplied software (standard cycles)
● Function Manual Basic Functions; W1: Tool offset
Section: "Tool holder with orientation capability" > "Oblique machining with 3 + 2 axes"
● Programming Manual, measuring cycles: CYCLE996
Activating the swivel function
The swivel function is enabled on the user interface via the following channel-machine data:
MD52212 $MCS_FUNCTION_MASK_TECH Cross-technology function screen
Bit 0 = 1 Enable swivel
Configuring input screens
You can configure the input screen for swiveling using the following channel-specific cycle
setting data. The setting data is effective for all of the declared swivel data sets.
SD55221 $SCS_FUNKTION_MASK_SWIVEL_SET Function screen, swiveling CYCLE800
Bit 0 Input field "No swiveling"
= 0 Hide
= 1 Display
Bit 1 Select text when retracting "Z, ZY" or "Fixed position 1/2"
= 0 Display text Z = "Z", display text Z, XY = "Z,XY"
= 1 Display text Z = "Fixed point 1", Display text Z, XY = "Fixed point 2".
If you wish to modify the retraction version "Z" or "Z, XY" via the manufacturer cycle
CUST_800.SPF, the neutral text "Fixed point 1" and "Fixed point 2" can be displayed.
Bit 2 Select, permit "deselection" of the swivel data set
= 0 If deselection is not permitted, the "Swivel data set" (TC) selection field is not displayed
in the "Swivel" input screen.
= 1 Deselection permitted
see also swivel data set parameter $TC_CARR37
HUNDRED MILLIONS position
Bit 3 Displays the active swivel plane under swivel in JOG. The setting in the swivel function
screen acts on all swivel data sets.
Bit 4 Positioning in the basic position (pole position) of the kinematics
= 0 Evaluation of the input values in pole position of the machine kinematics
= 1 Compatibility
Bit 5 Tool alignment absolute or via frame calculation
= 0 Tool alignment via frame calculation (TCOFRY for G18)
= 1 Tool alignment absolute (TCOABS)
For B axis kinematics of a turning machine, the tool spindle can be set in the basic position
of the kinematics, either parallel to Z or to X. Therefore the function "Align milling tool" is
required for rotary milling machine bit 5 = 1.
Bit 6 Do not list swivel mode "direct" under swivel in JOG
Bit 7 Swivel plane: Direction selection in basic position of the kinematic
Technologies and cycles
21.7 Swiveling
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 559
