$TC_CARR37[n] Display variants of the input screens for CYCLE800
Decimal place Meaning
HUNDRED MILLION Swivel data set enabled
Setting swivel data set change
Automatic or manual tool change is only necessary under ShopMill or Shop‐
Turn (→ see also: CUST_800.spf, markers _M2 to _M13).
A swivel data set must be "enabled" in every case (value ≥ 4).
0 = Swivel data set not enabled
4 = Swivel data set enabled
automatic swivel data set and tool change
5 = Swivel data set enabled
automatic swivel data set change and manual tool change
6 = Swivel data set enabled
manual swivel data set change and automatic tool change
7 = Swivel data set enabled
manual swivel data set and tool change
Notes on the setting Basic position of the kinematics
1)
For turning machines (1st technology is turning) with a B axis, you can set whether the tool
is oriented toward "-Z" or toward "-X" in the basic position of the kinematics. This setting is
taken into account for "Align tool" and for "Swivel plane".
Align tool
For "Align tool", the programming of beta and gamma is machine-independent.
With the basic position setting "Working plane" or "-Z", beta = 0 also corresponds to this
basic position (compatibility).
With the basic position setting "-X", the B axis is re-oriented through 90° for beta = 0.
Swivel plane (new swivel plane)
With the basic position setting "Working plane" or "-Z" and active working plane G17, there
is no new tool orientation for swivel plane to basic position (compatibility).
With the basic position setting "-X" and active working plane G17, the tool orientation is
rotated 90° around Y for swivel plane to basic position.
Therefore, with the basic position setting "-X", milling is possible in a swiveled plane in different
working planes (G17 or G19).
The following settings and programming is not permitted and results in error messages:
Swivel plane, basic position -Z and G18 or G19 active
Swivel plane, basic position -X and G18 active
Technologies and cycles
21.7 Swiveling
SINUMERIK Operate (IM9)
576 Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1
