Select the "Program manager" operating area if you have the authoriza‐
tion for access level 3 (password: User).
2. Press the menu forward key and the "Prog. list" softkey.
The "Program List" window opens.
3. Press the "Manufacturer" softkey if you want to create a program list that
can be used for all machines of a certain series.
4. Place the cursor in the desired line (program number).
5. Press the "Select program" softkey.
The "Programs" window opens. The data tree of the NC memory with the
directories "Workpieces", "Part programs" and "Subprograms" is dis‐
played.
6. Place the cursor on the desired program and press the "OK" softkey.
The selected program is inserted in the first line of the list together with
its path.
- OR -
Enter the program name directly in the list.
If you are making entries manually, check that the path is correct (e.g. //
NC/WKS.DIR/MEINPROGRAMM.WPD/MEINPROGRAMM.MPF).
If required, the extension (.MPF) is added.
Note:
A syntax check is not performed.
With workpieces, make sure that there is a main program or a job list with
the same name in the workpiece itself.
7. To remove a program from the list, place the cursor on the appropriate
line and press the "Delete" softkey.
- OR -
To delete all programs from the program list, press the "Delete all" softkey.
General settings
3.12 Program selection
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 47
