Section Description
U1LED ... U16LED
The status bit address can be defined - different from the output
image - using these entries.
Note: The offsets from the HT 8 output image, for one or several
softkeys, are not taken into consideration.
VarIncLED
SBLLED
WCSLED
showVarIncLED
true When the increment mode is active, the icon is also
displayed on the "[VAR]" softkey.
false The icon is not displayed.
showSBLLED
true When the SingleBlock mode is active, then the icon
is also displayed on the "Single Block" softkey.
false The icon is not displayed.
showWCSLED
true When the SingleBlock mode is active, then the icon
is also displayed on the "Single Block" softkey.
false The icon is not displayed.
1. You can copy the sample file "slckcpf.ini" from the following directory: /siemens/sinumerik/
hmi/template/cfg
2. Store the file in the /oem/sinumerik/hmi/cfg or /user/sinumerik/hmi/cfg directory.
3. If you use your own icon, then locate it together with the corresponding resolution for HT 8
directory: /oem/sinumerik/hmi/ico/ico640 or /user/sinumerik/hmi/ico/ico640.
4. Open the file and make the appropriate settings.
Sample file "slckcpf.ini"
Template for the configuration of the
; HT8 control panel function menu
;
; To activate the settings remove the
; commentary ';' at the beginning of the line
;; Display settings of the user key softkey leds
[UserKeyLED]
; Filename of the LED icon
;UserKeyLEDIcon = led_green.png
; Alignment of the LED icon
;UserKeyLEDIconAlignment= AlignLeft | AlignTop
; Use following led map start address instead of calculating
DB7.MCP1Out
;UserKeyLEDMap = AB0
HT 8
24.3 Configuring the function display at user-specific keys (U keys)
SINUMERIK Operate (IM9)
Commissioning Manual, 12/2017, 6FC5397-1DP40-6BA1 689
