Tag identifier Meaning
CREATE_CYCLE_EVENT If the parser starts to process the tag CREATE_CYCLE, initially, the message <CRE‐
ATE_CYCLE_EVENT sent> is sent to the active form. This message can be used for pre‐
paring the cycle parameters, before the parser generates the NC operation from the pa‐
rameter list and the generation rule.
&5($7(&<&/(!
&5($7(B&<&/(B(9(17!
&5($7(B&<&/(B(9(17!
Syntax:
<CREATE_CYCLE_EVENT>
…
…
</CREATE_CYCLE_EVENT>
Example:
<SOFTKEY_OK>
…
<CREATE_CYCLE />
…
…
<SOFTKEY_OK>
…
…
<FORM>
<NC_INSTRUCTION>MY_CYCLE($P1, $P2)</ NC_INSTRUCTION >
…
…
<CREATE_CYCLE_EVENT>
<type_cast name="P1" type="int"/>
<OP> P1 = P1 * 150 </OP>
</CREATE_CYCLE_EVENT>
…
…
</FORM>
Generating user dialogs
1.7 XML identifier
Easy XML
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 23
