Tag identifier Meaning
DATA_LIST The tag enables the listed drive and machine data to be saved or restored.
Addresses are listed in lines. Chapter "Component addressing" (Page 85) describes how
addresses are formed.
Up to 20 temporary data lists can be created.
Attributes:
● action
read
– the values of the listed variables are stored in a temporary memory
append
– the values of the listed variables are added to an existing list
write
– the backed up values are copied to the relevant machine data
● id
The identifier identifies the temporary memory
Syntax:
<DATA_LIST action="<read/write/append>" id="<list name>">
NC/PLC address compilation
</DATA_LIST>
Example:
<DATA_LIST action ="read" id="<name>">
nck/channel/parameter/r[2]
nck/channel/parameter/r[3]
nck/channel/parameter/r[4]
$MN_USER_DATA_INT[0]
…
</ DATA_LIST>
<DATA_LIST action ="write" id="<name>" />
DO_WHILE Do while loop
DO
Instructions
WHILE (Test)
Syntax:
<DO_WHILE>
Instructions
…
<CONDITION>…</CONDITION>
</DO_WHILE>
The Do While loop comprises a block of instructions and a condition. The code in the in‐
struction block is executed first, then the condition is applied. If the condition is true, the
function executes the code section again. This is continually repeated until the condition is
false.
Example:
<DO_WHILE>
<DATA name = "PLC/qb11"> 15 </DATA>
<CONDITIION> "plc/ib9" == 0 </CONDITION>
</DO_WHILE>
Generating user dialogs
1.7 XML identifier
Easy XML
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 25
