Tag identifier Meaning
CONTROL The tag is used to generate control elements.
Syntax:
<CONTROL name = "<control name>" xpos = "<X position>" ypos = "<Y
position>" refvar = "<NC variable>" hotlink = "true" format =
"<format>" />
Note:
Variables used to set attribute values must be declared global variables.
Attributes:
● name
Identifier of the field.
The identifier simultaneously represents a local variable, and must not be used a multiple
number of times in the form.
● xpos
X position of the top left corner
● ypos
Y position of the top left corner
● fieldtype
Field type
If no type is specified, the field is set as an edit field.
– edit
Data can be changed
– readonly
Data cannot be changed
combobox
The field displays the corresponding identifiers instead of numerical values.
If field type combobox is selected, the expressions to be displayed must also be
assigned to the field.
The <ITEM> tag should be used for this purpose.
The combo box saves the index of the currently selected text in the variable belonging
to the control (see the attribute refvar).
After the control has been created, additional elements can be inserted using the
functions addItem or insertItem.
– progressbar
A progress bar with a value range of 0 to 100 appears.
The valley value and peak value properties can be used to adapt the value range to
the data to be displayed.
Generating user dialogs
1.7 XML identifier
Easy XML
Programming Manual, 12/2017, 6FC5397-1DP40-6BA1 61
