Identifier <tag> Meaning
SET_ACTIVE The identifier contains a description of the sequences required to
activate the device.
Attributes:
● timeout
The attribute permits a timeout to be specified in seconds. The
system interrupts processing if the script has still not been
completed after this time.
SET_INACTIVE The identifier contains a description of the sequences required to shut
down the device.
Attributes:
● timeout
The attribute permits a timeout to be specified in seconds. The system
interrupts processing if the script has still not been completed after
this time.
TEST The identifier contains the statements for testing the operating capa‐
bility of a device.
Attributes:
● timeout
The attribute permits a timeout to be specified in seconds. The system
interrupts processing if the script has still not been completed after
this time.
UID Unique numerical identifier to identify the device in the PLC ↔ HMI
interface.
VERSION Identifier for a version
Negative acknowledgment of the function execution
With the automatically provided variable "$actionresult", the system can inform the XML parser
of a negative execution result. If the value is set to zero, the parser aborts the function
processing.
Example
<?xml version="1.0" encoding="utf-8"?>
<!DOCTYPE AGM>
<AGM> Identifier for the "Startup Wizard"
<DEVICE>
<NAME> Device 1 </NAME> Identifier for the device
<START_UP>
…
</START_UP>
Identifier for commissioning the device
<SET_ACTIVE>
…
</SET_ACTIVE>
Identifier for activating the device
Generating commissioning dialogs
2.7 Script language
Easy XML
188 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
