Tools
● UTF8-capable editor (e.g. the integrated editor of the user interface or Notepad)
● A graphics program is needed to create graphics/display images.
File names and coding
Note
When using HMI Operate in the NCU, note that all file names are written in lower case letters
(com, png, txt) on the CF card. This is required because of Linux.
File names are not case-sensitive on the PCU. However, it is recommended that you also use
lower case letters here, in case of a possible subsequent transfer to Linux.
Note
When saving configuration and language files, ensure that the coding is set to UTF-8 for the
editor you are using.
Storage paths
Note the following convention when storing the configuration files, language files, etc.
[System Siemens directory]
Linux: /card/siemens/sinumerik/hmi
Windows 7: C:\ProgramData\Siemens\MotionControl\siemens
[System oem directory]
Linux: /card/oem/sinumerik/hmi
Windows 7: C:\ProgramData\Siemens\MotionControl\oem
[System user directory]
Linux: /card/user/sinumerik/hmi
Windows 7: C:\ProgramData\Siemens\MotionControl\user
[System add_on directory]
Linux: /card/addon/sinumerik/hmi
Windows 7: C:\ProgramData\Siemens\MotionControl\addon
Storage locations
"Run MyScreens" configuration:
[System oem directory]
/proj
Configuration file:
[System oem directory]
/cfg
Language files:
[System oem directory]
/lng
Introduction
SINUMERIK Integrate Run MyScreens (BE2)
10 Programming Manual, 12/2017, 6FC5397-1DP40-6BA1
