2.2 UNPACKING
To remove the machine from its packing:
1) Cut the straps and remove.
2) Raise the top part of the cardboard box.
3) Loosen the screws xing the front and rear brackets holding the machine to the pallet.
4) Use the special key to loosen the nuts on the feet by a couple of turns.
5) Remove the metal brackets and tighten the nuts on the feet.
6) Check the contents of the packing:
- 1 TRIAX PRO key-cutting machine
- 1 Machine documentation: operating manual, spare parts list, expert guide and warranty form
- 1 Power lead
- 1 Tool box
2.3 MACHINE HANDLING
Once removed from the packing place TRIAX PRO directly on a workbench; the operation should be carried out
by at least 2 persons.
ATTENTION: when lifting the machine take hold of the base only (Fig. 8). Never lift the machine by holding
onto the keypad support (Fig. 9).
Fig. 8 Fig. 9
YES
NO
