Silca Triax Pro - Work Station Description; Separate Parts; Power Cable; Warning Label

3.4 WORK STATION DESCRIPTION
Only one operator is required to work the key-cutting machine and the following controls are available:
1) Master switch on the back of the machine.
2) Key-positioning clamp.
3) Control keypad.
4) Display.
5) Emergency button.
3.5 SEPARATE PARTS
The separately packed parts must be installed on the key-cutting machine
by the purchaser, as follows:
3.5.1 Power cable
Connect the key-cutting machine power cable to the electricity mains (Fig.
11).
Fig. 11
3.5.2 Warning label
Place the adhesive label in the appropriate language in position as shown in Fig. 12.
provided (Ch.1.1)
Fig. 12
NOTE: it is forbidden to remove the labels.
Operating manual TRIAX PRO
Copyright Silca 2016
15
