01J
A8 A6
02J
R29
position
R28
position
Fig. 15 - R29 position: CUTTING
R29
position
R28
position
Fig. 16 - R28 position: ENGRAVING
Operating manual TRIAX PRO
Copyright Silca 2016
18
