FAULT CHECK PROBABLE CAUSE
The X axis upper carriage
moves to the left or right and
knocks against the machine
limit switch.
Use tests digital inlets to check the photocell sensor.
Check fuse F4 on the circuit board.
Check the X axis connecting wire (J1).
Control circuit board faulty.
The Y axis lower carriage
moves towards the operator
or the front part and knocks
against the machine limit
switch.
Use tests 6 and 9 to check the photocell sensor.
Check fuse F4 on the circuit board.
Control circuit board faulty.
The Z axis carriage moves
upwards and knocks against
the machine limit switch,
or moves downwards and
knocks against the clamp.
Use tests 7 and 10 to check the photocell sensor.
Check fuse F4 on the circuit board.
Control circuit board faulty.
The display shows the
message “Spindle ALARM
check and t tool and position
locking lever”.
Check lever position.
Check for swarf on the top part of the cutter spindle
Operating manual TRIAX PRO
