• 1 fuse F5:
1,6 Ampere ritardato (230V)
2 Ampere ritardati (100V)
Protects the main electronic circuit board transformer.
Situated in the bottom of the base.
F5
Fig. 42
• 2 fuses: F6, F7:
1 fuse: F6: 8 Amps delayed
Protects motor power.
1 fuse: F7: 1 Amps delayed
Protects the motor circuit board.
Situated on the motor circuit board at the rear of the base.
Fig. 43
Operating manual TRIAX PRO
Copyright Silca 2016
86
