Smeg WD7010 - ELECTRICAL POWER SUPPLY

USER MANUAL
WD6010 – WD7010 – WD7015
Page 166 - 168
ELECTRICAL POWER SUPPLY
DESCRIPTION
ELECTRICAL POWER
SUPPLY
CABLE SUPPLIED
ADVIDSED
CIRCUIT BREAKER
[ required on the
building side ]
WD6010 - WD7010
ELECTRICAL
CONNECTION
50Hz
DEFAULT 400V
(Default
connection)
400V 3N~ / 50Hz /
24A / 13000W
H07RN-F 5 x 6
mm
2
(5G6),
450/750V
3P+N, 32A,
400V, 4,5kA
(Pdi min.)
THREE-PHASE
VARIANT 230V
WITHOUT
NEUTRAL
230V 3~ / 50Hz / 36A
/ 13000W
H07RN-F 4 x 6
mm
2
(4G6),
450/750V
3P, 40A,
400V, 4,5kA
(Pdi min.)
WD6010
ELECTRICAL
CONNECTION
60Hz
DEFAULT 400V
(Default
connection)
380-400V 3N~ / 60Hz
/ 24A / 13000W
H07RN-F 5 x 6
mm
2
(5G6),
450/750V
3P+N, 32A,
400V, 4,5kA
(Pdi min.)
THREE-PHASE
VARIANT 230V
WITHOUT
NEUTRAL
220-230V 3~ / 60Hz /
36A / 13000W
H07RN-F 4 x 6
mm
2
(4G6),
450/750V
3P, 40A,
400V, 4,5kA
(Pdi min.)
WD7010
ELECTRICAL
CONNECTION
60Hz
DEFAULT 400V
(Default
connection)
380-400V 3N~ / 60Hz
/ 24A / 13000W
H07RN-F 5 x 6
mm
2
(5G6),
450/750V
3P+N, 32A,
400V, 4,5kA
(Pdi min.)
THREE-PHASE
VARIANT 230V
WITHOUT
NEUTRAL
220-230V 3~ / 60Hz /
36A / 13000W
H07RN-F 4 x 6
mm
2
(4G6),
450/750V
3P, 40A,
400V, 4,5kA
(Pdi min.)
WD7015
ELECTRICAL
CONNECTION
50Hz
DEFAULT 400V
(Default
connection)
400V 3N~ / 50Hz /
30A / 20000W
FG16OR16-0,6/1
kV 5 x 10 mm
2
(5G10),
450/750V
3P+N, 40A,
400V
THREE-PHASE
VARIANT 230V
WITHOUT
NEUTRAL
230V 3~ / 50Hz / 45A
/ 17000W
FG16OR16-0,6/1
kV 4 x 10 mm
2
(4G10),
450/750V
3P, 50A, 400V
ELECTRICAL
CONNECTION
60Hz
DEFAULT 400V
(Default
connection)
380-400V 3N~ / 60Hz
/ 30A / 20000W
FG16OR16-0,6/1
kV 5 x 10 mm
2
(5G10),
450/750V
3P+N, 40A,
400V
THREE-PHASE
VARIANT 230V
WITHOUT
NEUTRAL
220-230V 3~ / 60Hz /
45A / 17000W
FG16OR16-0,6/1
kV 4 x 10 mm
2
(4G10),
450/750V
3P, 50A, 400V
