USER MANUAL
WD6010 – WD7010 – WD7015
Page 167 - 168
OTHER DATA
DATA
COMMUNICATION
USB SERIAL PORT
(ON LOADING SIDE OF DEVICE)
LAN PORT
(OPTIONAL - ON TOP OF DEVICE)
RS232 FOR REMOTE PRINTER
(OPTIONAL PORT PROVIDED ON TOP OF DEVICE, INSTALLABLE IF THE PANEL PRINTER IS NOT INSTALLED)
MAX. NOISE
66 dBA
ENVIRONMENTAL CONDITIONS
USE
Internal
ALTITUDE
Up to 1000m
ENVIRONMENT TEMPERATURE
From 10°C to 40°C
MINIMUM LIGHTING LEVEL REQUIRED
300 lx
WD6010, WD7010
WD7015
HEAT EMISSION INTO THE ROOM - CYCLE RUNNING
(assessed considering a cycle containing a 93°C thermal disinfection cycle -
not including the heat emitted by the steam vent)
1000 W
(3500 BTU/h)
1500 W
(5250 BTU/h)
MAX. RELATIVE HUMIDITY
80% for temperature up to 31°C with lineal
decrease to 50% at the temperature of 40°C.
INSTALLATION CATEGORY (or OVERVOLTAGE
CATEGORY)
II
ELECTRICAL INSULATION CLASS (ref. IEC 61140)
I
POLLUTION DEGREE
2 (ref. 61010-1:2010, par.3.6.8)
REGULATIONS AND CLASSIFICATION
WD CONFORMITY
- European directive 2014/35/EU [Safety]: European Standard EN61010-1:2010,
EN61010-2-040:2015
- European directive 2014/30/EU [Emc] : European Standard EN61326:2013
- Other: European Standard EN 61770:2009
- European directive 2011/65/CE [RoHS 2] : European Standard EN 50581 :2012
- European directive 93/42/CE, 2007/47/CE [MD]: European Standard
EN ISO 14971:2012, EN 62304:2006+AC:2008, EN62366:2008, EN ISO 15883-
1:2014, EN ISO 15883-2:2009
MEDICAL DEVICE
CLASS
II b (in compliance with the criteria approved by the Directive 93/42 and later
changes and additions, integrated and modified by the directive CE 2007/47)
