Loading the chamber using the multi-purpose trolley.
Loading side – opening the door at the bottom gives access to:
- detergent jerrycan compartment (detergent jerrycans and intake nozzle)
- dryer air filters
- peristaltic pumps (liquid detergent dispensing pumps).
WARNING:
If the detergent compartment is open, the loading side door cannot be operated.
PERISTALTIC
PUMPS
DRYER FILTERS
DETERGENT
JERRYCAN
COMPARTMENT
